Bel Power Solutions RQB-50Y 50W Isolated DC-DC Converters

Bel Power Solutions RQB-50Y 50W Isolated DC-DC Converters are specifically designed for a variety of railway applications and feature 50W single output voltage. These high-performance products offer a wide 12:1 input voltage from 14V_DC to 160V_DC, high efficiency of up to 90%, and an extended operating temperature range from -40°C to +105°C. Protections include input undervoltage, output overvoltage, short circuit, overcurrent, and overtemperature. Other features include remote sense compensation, remote on/off control, programmable undervoltage lockout, hold-up function, and output voltage trim adjustment. Bel Power Solutions RQB-50Y 50W Isolated DC-DC Converters are offered in an industry-standard 1/4-brick package and pin-out with IEC 62368-1 safety approvals. The series also meets EN 50155 and AREMA standards.
