Analog Devices / Maxim Integrated MAX25405 Evaluation Kit

Analog Devices MAX25405 Evaluation Kit is a complete system for demonstrating the MAX25405 optical IR sensor in a typical gesture and proximity-sensing application. The MAX25405 IR Gesture Sensor is a low-cost, flexible gesture-sensing solution for automotive applications. The MAX25405 integrates a complete optical system including lens, aperture, visible light filter, and a 6×10 photodetector array.

The Analog Devices MAX25405 Evaluation Kit is fully assembled and tested. The Kit includes a USB 2.0 Type A to Micro B cable and 3.3V power supply.

Features

Simple yet flexible gesture solution
Lower solution cost than camera-based systems
Integrated optics with ±20deg Field of View (FOV)
Optimum resolution for dynamic hand gestures
Built-in LED driver with ultra-low-power operation

120kLux Ambient light performance
Compact 20-pin, 4mm x 4mm QFN package, side wettable
AEC-Q100
-40°C to +85°C Operation

Kit Contents

MAX32620FTHR Microcontroller platform
Interface shield board
MAX25405 Sensor board

Ribbon cable (connects sensor board to shield board)
3.3V Power supply
USB 2.0 type A to micro B cable

Required Equipment

MAX25405 EV kit
Included USB 2.0 Type A to Micro B cable

Included 3.3V power supply
Windows PC running the Maxim Gesture Sensor EV kit graphical user interface (GUI)
