Analog Devices / Maxim Integrated MAX20459EVKIT Evaluation Kit

Analog Devices MAX20459EVKIT Evaluation Kit is designed to quickly and easily demonstrate the MAX20459. The MAX20459 Automotive High-Current Step-Down Converter integrates a 3A high-efficiency, automotive-grade, step-down converter, a USB Type-C DFP controller, and automatic BC1.2 DCP, Apple®, plus Samsung® dedicated charger-detection circuitry.

The ADI MAX20459EVKIT Evaluation Kit provides a standalone enabled MAX20459ATJC/V+ that is configured by pull-down resistors. The I2C variant (MAX20459ATJA/V+) allows for flexible configuration, detailed fault diagnostics, and access to the on-chip ADC that reports die temperature, output voltage, and output current. The I2C features are easily reached by using the ADI MINIQUSB module along with the provided example GUI.

Features

  • Configurable Charge-Detection Modes
    • USB-C 3.0A, 1.5A, 0.5A
    • USB-IF BC1.2 DCP
    • Apple 2.4A, 1.0A
    • Samsung 2.0A
    • China YD/T 1591-2009 Charging Specification
  • Automatic USB Voltage Adjustment by Integrated DC-DC Converter (275kHz – 2.2MHz)
  • Proven PCB Layout
  • Fully Assembled and Tested

Features

  • MAX20459 EV kit
  • USB Type-C to Type-C cable
  • 14V/2A DC Power Supply or car battery (VBAT)
  • USB-C amperage meter (Plugable USBC-VAMETER recommended)
  • USB-C device (smartphone recommended)
  • Two jumpers: VBAT, GND

Standalone Kit Interface
