Analog Devices Inc. MAX17623/MAX17624 Step-Down Converters are part of the Himalaya series of products that enable cooler, smaller, and simpler power supply solutions. The MAX17623 and MAX17624 are high-frequency converters with integrated MOSFETs and internal compensation. The MAX17623/MAX17624 offer an input-voltage range of 2.9V to 5.5V, supports up to 1A, and output voltage can be adjusted from 0.8V to 3.3V.
ADI MAX17623/MAX17624 Step-Down Converters employ peak-current mode control architecture under steady-state operation. To reduce input-inrush current, the Converters deliver a fixed 1ms soft-start time. Both devices feature selectable PWM for fixed-frequency operation or PFM mode for better efficiency at light loads. When PWM mode is selected, MAX17623 operates at a fixed 2MHz switching frequency, and MAX17624 runs at a fixed 4MHz switching frequency. MAX17623 supports output voltages from 0.8V to 1.5V, and MAX17624 offers output voltages from 1.5V to 3.3V.
The MAX17623 and MAX17624 devices are available in a compact 8-pin, 2mm × 2mm TDFN package.
