Analog Devices Inc. MAX17227A Switching Voltage Regulator is a 2A nanoPower boost converter with short-circuit protection and true shutdown. This switching regulator delivers load up to 2A peak inductor current and offers cycle-by-cycle inductor current limit and thermal protection. The MAX17227A regulator offers ultra-low quiescent current, small total solution size, and high efficiency throughout the load and line range. This switching regulator disconnects the output from the input with no forward or reverse-current which saves energy for the battery. The MAX17227A device operates across 0.4V to 5.5V wide input voltage range.
Analog Devices MAX17227A switching regulator operates from -40°C to 125°C temperature range. This voltage regulator is offered in a space-saving 1.58mm x 0.89mm, 6-bump WLP (3 x 2, 0.4mm pitch) and 8-pin, 2mm x 2mm TDFN packages. The MAX17227A regulator is ideal for battery-powered applications where long battery life is a must and high efficiency is required at all power levels. Applications include WiFi module, near-band IoT, wearable audio, emergency lighting, IoT sensors, and clinical instrumentation.
