Analog Devices Inc. DC3126A Demonstration Circuit

Analog Devices Inc. DC3126A Demonstration Circuit offers a quad power supply based on the LT8686S. The LT8686S is a 42V quad channel current mode monolithic synchronous step-down regulator. The DC3126A supplies two 42V regulators that can be combined to provide up to 4A output current using a singular inductor. Likewise, using a singular inductor, the two 8V regulators can be connected to provide up to 4A output current. The ADI DC3126A Demonstration Circuit has an EMI filter installed on the bottom layer.
