Analog Devices Inc. ADRF5043-EVALZ Evaluation Board

Analog Devices Inc. ADRF5043-EVALZ Evaluation Board is designed to evaluate the ADRF5043 Silicon SP4T Switches. The ADRF5043 9kHz to 44GHz, nonreflective, SP4T switch is manufactured in the silicon on insulator (SOI) process.

The ADI ADRF5043-EVALZ Evaluation Board uses the same printed circuit board (PCB) for both the ADRF5042 and the ADRF5043.

Features

  • Contains the ADRF5043 device and application circuitry
  • 2.4mm RF connectors
  • DC test points for supply and control through line for calibration

Required Equipment

  • DC power supplies
  • Network analyzer

Layout

Analog Devices Inc. ADRF5043-EVALZ Evaluation Board
