Analog Devices Inc. ADMV8913-EP MMICs

Analog Devices Inc. ADMV8913-EP MMICs feature a digitally selectable operating frequency. In addition, the ADMV8913-EP has an integrated high-pass filter (HPF) and an integrated low-pass filter (LPF) that enable a pass-band response within the 6.6GHz to 11.9GHz frequency range.

The ADMV8913-EP MMICs offer a flexible architecture allowing for the 3dB cutoff frequency (f_3dB) of the high-pass and the low-pass filter to be
controlled independently. The digital logic control on each filter is 4 bits wide (16 states) and controls the on-chip reactive elements to adjust the f_3dB. The typical insertion loss is 5.3dB, and the wideband rejection is 35dB, which is ideal for minimizing system harmonics. This tunable filter can be used as a smaller alternative to large switched filter banks and cavity-tuned filters.

The ADMV8913-EP provides a dynamically adjustable solution in advanced communications applications.

Features

Digitally tunable, lower, and upper 3dB cutoff frequencies
Optimal wideband rejection of 35dB
Single chip replacement for discrete filter banks
Compact 6.00mm x 3.00mm x 0.89mm LGA package
Enhanced features
- Supports defense and aerospace applications (AQEC standard)
- Military temperature range (such as -55°C to +105°C)
- Controlled manufacturing baseline
- One assembly/test site
- One fabrication site
- Enhanced product change notification
- Qualification data available on request

Applications

Test and measurement equipment
Military radar and electronic warfare and electronic countermeasures

Satellite communications
Industrial and medical equipment
