ams OSRAM AS7343 14-Channel Multi-Spectral Sensors integrate high-precision optical filters onto standard CMOS silicon via deposited interference filter technology. These AS7343 sensors feature a spectral response that is defined by individual channels covering approximately 380nm to 1000nm with 11 channels centered in the visible spectrum (VIS), plus one near-infrared (NIR), and a clear channel. The AS7343 also includes an integrated flicker detection channel that can automatically flag ambient light flicker at 50Hz/60Hz, as well as buffer data for externally calculating other flicker frequencies.
The sensors are optimized for transmissive, reflective, and emissive measurements, including fluid or reagent analysis, color matching, spectral identification in the visible range, and lateral flow test applications. The AS7343 Multi-Spectral Sensors from ams OSRAM are available in an ultra-low profile package with dimensions of 3.1mm x 2mm x 1mm.
