Amphenol Times Microwave Systems PhaseTrack® 047 (PT-047) Micro Coaxial Cables

Amphenol Times Microwave Systems PhaseTrack® 047 (PT-047) Micro Coaxial Cables are low-loss, highly flexible foam-core micro coax cables. The Amphenol Times Microwave Systems PT-047 is designed for space satellite programs with high-performance characteristics, such as a -65°C to +150°C operating temperature range, making the series ideal for use in a wide variety of applications. The broad frequency range (up to 70GHz) and strong durability are useful in medical, test equipment, and RF designs.

Features

High performance in a compact size
Extremely rugged and low loss
Broad frequency range up to 70GHz

Flex tested to over a million cycles
In-the-box flexible alternative to 047 Semi-Rigid

Applications

Aerospace and defense
Test and measurement

5G and telecom
Medical equipment

Specifications

1.52mm maximum diameter
6.35mm bend radius (centerline)
83.3pF/m capacitance
4.17ns/m delay
0.52dB/m insertion lossat 18GHz

81% velocity of propagation
50Ω impedance
90dB shielding
-65°C to +150°C operating temperature range
