Amphenol Sine Systems Panel Rack-Mount PRM Series™ Power Connectors

Amphenol Sine Systems Panel Rack-Mount PRM Series™ Power Connectors are available in both plugs and receptacles. The PRM series provides a quick-connect power connector solution for use in panel rack-mount network applications. These Amphenol Sine Systems connectors are keyed to prevent mismating / reverse polarity and feature RADSOK® and SureSocket™ contacts. The quick-connect design of these PRM connectors enables denser installations, faster deployments, and upgrades.

Features

Available in 2 position
Field installable with standard crimpers
Stackable / reduced footprint / in-line wire design
Faster installations / replacements

Keyed to prevent mismating / reverse polarity
RADSOK and SureSocket contacts
Panel receptacles can be customized to specific applications

Applications

Telecommunications infrastructure
Data centers
Broadband

Specifications

-40°C to +125°C operating temperature range
Up to 70A current
250V maximum voltage
GF PA 6/6 housing body
>500 mating cycles
Contact sizes
- 2.4mm: 0.216 (5.5mm)
- 4.0mm: 0.315 (8mm)

Number/size of contacts
- 2/2.4mm (SureSocket)
- 4.0mm (RADSOK)
Contact barrel range
- 2.4mm: 10AWG to 20AWG
- 4.0mm: 6AWG to 16AWG
UL 94V-0 flammability rating
