Allegro MicroSystems CT452 1MHz Bandwidth Contactless Current Sensor

Allegro MicroSystems CT452 1MHz Bandwidth Contactless Current Sensor is a high bandwidth low noise integrated zero-loss contactless current sensor. The CT452 uses patented XtremeSense® TMR technology. This enables high-accuracy current measurements for consumer, enterprise, and industrial applications. The device supports six field ranges where the CT452 senses and translates the magnetic field into a linear analog output voltage. It achieves a total error output of less than ±1.0% over voltage and temperature.

Features

Integrated contactless current/field sensing ranges
- 0mT to +6mT
- -6mT to +6mT
- 0mT to +12mT
- -12mT to +12mT
- 0mT to +24mT
- -24mT to +24mT
Linear analog output voltage
-50dB common mode field rejection
≤ ±1.0%, -40°C to +125°C total error output
1MHz bandwidth
