Allegro MicroSystems AHV85111 Self-Powered Isolated GaN FET Driver is designed to drive GaN FETs in multiple applications and topologies. The AHV85111 integrates an isolated dual positive/negative output bias supply, eliminating the requirement for any external gate drive auxiliary bias supply or high-side bootstrap. The bipolar output rails, with adjustable and regulated positive rail, improve dv/dt immunity, dramatically simplify the system design, and reduce EMI through decreased total common-mode (CM) capacitance.
The Allegro AHV85111 Driver can power a floating switch in any location with a switching power topology. The device has a fast propagation delay and high peak source/sink capability to drive GaN FETs in high-frequency designs efficiently. The device is ideal in applications demanding isolation, level-shifting, or ground separation for noise immunity by implementing high CMTI combined with isolated outputs for both bias power and drive.
The AHV85111 is housed in a compact, low-profile surface-mount NH package. The device provides several protection features, including integrated undervoltage lockout on primary and secondary bias rails and internal pull-down on IN and OUTPD pins. A fast response enables input, overtemperature shutdown, and OUT pulse synchronization with the first IN rising edge after allowing (avoids asynchronous runt pulses).
